REX-USB61
Product Details
SPI/I2C Protocol Emulator
REX-USB61
Product overview
REX-USB61 SPI/I2C Protocol Emulator converts PC USB transactions to the SPI/I2C Bus.
REX-USB61 enables you to easily control from a PC a variety of devices with SPI/I2C Bus.
This product includes SPI/I2C control utility software.
The SPI/I2C control utility can control SPI/I2C devices and GPO(General Purpose Output) signals.
It also can save setting parameter and logging data to the file.
REX-USB61 enables you to easily control from a PC a variety of devices with SPI/I2C Bus.
This product includes SPI/I2C control utility software.
The SPI/I2C control utility can control SPI/I2C devices and GPO(General Purpose Output) signals.
It also can save setting parameter and logging data to the file.
This product is the Japanese version, but it is available in English version of Windows.
You can download User's Manual in English(pdf) and Sample programs in English.
Features
- Supports both serial Bus interface SPI and I2C.
- Supports SPI Bus master mode.
- Supports both I2C Bus mode master and slave.
- Can be supplied power to the products and devices connected by itself
- Includes split Cable with Housing connector
- Includes utility software for operating the SPI/I2C Bus protocol
- Batch scripting capability with the REX-USB61 Batch Script language.
- Includes library for supporting the application development.
- Supportted Computer
Windows PC with Hi-Speed USB(480Mbps) ports - Supported Operationg System
Windows 8/7/Vista/XP
*Also works on 64bit version.
Specifications
Hardware specifications
| Items | Specification |
|---|---|
| Host Interface | USB2.0 Full Speed Device |
| Connector | USB mini B connector |
| Voltage | 5V (via USB bus power) |
| Consumption Current | 100mA |
| Device Interface | SPI Master Max. frequency 12MHz I2C Master/Slave Frequency 47KHz～1MHz |
| Input/Output level | [Output] 3.3V/5V [Input] 1.8V/5.0V is enabled with external P/S |
| Dimension | 57(W) x 75(D) x 18(H) mm |
| Weight | Approx.60g (except cable) |
| Operating environment | Temperature:5～55℃ Humidity:20～80% (non condensing) |
* REX-USB61 can only use 1 device. On the other hand, REX-USB61M can use multiple devices.
Software List
| Title | Name | Description |
|---|---|---|
| Setting file | usb61.inf | For Windows Vista/XP/XP x64/2000 Setting file for REX-USB61 |
| Installer | Setup.exe | For Windows7/7 x64/Vista x64 Installer |
| Utility | Usb61Uty.exe | Utility to control SPI/I2C |
| Script file | I2C_scrupt.txt SPI_script.txt |
REX-USB61 Batch Script file |
| Sample program | EEPROMRWUty I2CSlaveSample |
Sample program to send/receive SPI/I2C Sample program for I2C slave (VC6.0/VB6.0/VB2005/C#) |
| Library | usb61api.dll usb61def.h usb61api.bas usb61api.vb |
Library to control SPI/I2C devices Header file for Visual C Module for Visual Basic Code file for Visual Basic |
| ActiveX control | usb61api.ocx | ActiveX control |
| Uninstall utility | USB61_uninst.exe | For Windows XP/XP x64/2000 Utility to delete INF file |
| Product | USB61mk2 | USB61 |
| High Grade model | Standard model | |
| ■SPI | ||
| Frequency (SCK) |
762Hz～50MHz *1 | 1kHz～12MHz *1 |
| Bus width | Single/Dual/Quad | Single |
| Device Mode |
Master / Slave (Slave 2ch) | Master only |
| Transfer size | 32bit(Max) | 8bit |
| ■I2C | ||
| Frequency (SCL) |
100kHz, 400kHz, 1MHz, 3.4MHz, 5MHz 762Hz～5MHz *1 |
100kHz/400kHz/1MHz (5V only for over 400kHz), 47kHz～1MHz *1 |
| Communication mode | Standard-Mode, Fast-Mode, Fast-Mode Plus, High-Speed, Ultra Fast-Mode |
Standard-Mode, Fast-Mode |
| Device mode | Master / Slave (Slave 2ch) | Master / Slave |
| Address mode |
10bit/7bit | 10bit/7bit (Slave mode support 7bit only) |
| ■Common specifications | ||
| Power supply for devices | 1.8V, 2.5V, 3.3V, 5.0V (Max100mA) | 3.3V, 5.0V(Max100mA) |
| DIO |
8bit （Each 1bit can switch IN/OUT) | DO 4bit（Only when I2C is used) |
| Script control function | Communication mode, setting for speed, Read/Write from/to each device, Read from files, Save to files, bit operation, branch/registers(16pcs)/ dialog display |
Communication mode, setting for speed, Read/Write from/to each device, Read from files, Save to files |
| Virtual COM mode | Communication mode, setting for speed, Read/Write from/to each device/DIO control |
non-support |
| Connection to PC | USB2.0 Hi-Speed Micro-B | USB2.0 Full-Speed Mini-B |
| Supported OS | Windows 10, 8.1, 8, 7, Vista ※Compatible with both 32bit・64bit |
Windows 10, 8.1, 8, 7, Vista, XP(SP2), 2000(SP4) ※Compatible with both 32bit・64bit |
| Sample program | Visual C++ 2010, 2005, 6.0 Visual C# 2010, 2005 Visual Basic2010, 2005, 6.0 |
|
| Dimension・Weight(except cable) |
2.72[L] x 4.53[W] x 0.77[H] in (69[L]×115[W]×19.5[H] mm) Approx. 3.46oz (Approx. 98g) |
2.25[L] x 2.96[W] x 0.71[H] in (57[L] x 75[W] x 18[H] mm) Approx. 2.12oz(Approx.60g) |
| Accessories | Body, USB cable（Approx. 3.28ft (Approx. 1m)), 20pin device cable 5.91in(15cm)), CD-ROM（Drivers, Software, User's manual), Warranty card | |
| *1 Approximation calculated by controller inside of USB61/USB61mk2 |
